Introduction

This is a Cesium development kit that includes functionalities such as layer loading, coordinate conversion, coordinate picking, camera control, measurement, plotting, model loading and manipulation (translation, rotation scaling), 3Dtiles view position adjustment, weather effects (rain, snow, fog), scene rendering with radar scan and information box display capabilities. It also provides features for flow line visualization, lighting effects including dynamic wall and other luminous materials rendering. Additionally it supports Post effects, visibility analysis tools for perspective analysis and slope analysis. Furthermore it offers Inundation analysis as well as volume analysis capabilities and terrain excavation functionality.

Features

material	analysis	plot
dynamicRiver	extrude	effect
radar	roaming	drag
rayCast	fireworksEffect	aniSoldier
pathPlan

More>>

Install

npm install cesium_dev_kit

Use

1、Import all

The initialization of 'initCesium' allows for the acquisition of all extension modules.

 import { initCesium } from 'cesium_dev_kit'
  const {  viewer,  material, ... } = new initCesium({  cesiumGlobal: Cesium,containerId: 'cesiumContainer',...})

2、Import on demand

The import of a single extension class can be tailored to meet specific functional requirements, thereby minimizing code redundancy.

import {Graphics} from 'cesium_dev_kit'
const {viewer,graphics} = new Graphics({
      cesiumGlobal: Cesium,
      containerId: 'cesiumContainer'
  })
  graphics.getPointGraphics({
      color:Cesium.Color.GREEN,
      pixelSize:5,
      outlineColor:Cesium.Color.WHITE,
      outlineWidth:1
  })

Used in h5

• Import index.umd.js directly into html

• Initialize object

new cesium_dev_kit.initCesium({...})

See API documentation 📑 (Cheap server, please be patient) for more details...

Use example

• Vue Use case https://github.com/dengxiaoning/cesium_kit_test

• React Use case https://github.com/dengxiaoning/react-cesium

• H5 Use case https://github.com/dengxiaoning/cesium_kit_test_h5

Donate

Do you use and like cesium_dev_kit but you don’t find a way to show some love? If yes, please consider donating to support this project. Otherwise, no worries, regardless of whether there is support or not, I will keep maintaining this project. Still, if you buy me a cup of coffee I would be more than happy though😄

•

• WeChat / AliPay



Browser support

The 'Chrome 80+' browser is recommended for local development

Modern browsers (chrome, Firefox, Microsoft edge, etc.) are supported. Internet Explorer is not supported

Thanks

cesium-d3kit
drawarrowforcesium
vue3-ts-cesium-map-show

This project includes but is not limited to the reference and reference of the above materials, thank you very much for sharing

Project deficiency and optimization

• 1、Extended classes not using type detection (TS)
• 2、No exception catching and handling

How to contribute

This project exists thanks to all the people who contribute.

• If you want to contribute, you can Raise an issue Or submit a Pull Request.

See CONTRIBUTING for more details on donations...
